    AX525-B

    159.00

    Available points: 0 Points Points reward: 159 Points

    Quantity：

    159.00

    USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

    • Detail information
    • Specifications

    Hot Products

    ax

    AX SERIES BRUSHLESS MOTORS

    A POWER SYSTEM SPECIFICALLY ENGINEERED FOR FIXED-WING CRUISE UAVS

    AX435-A | AX435-B | AX525-A | AX525-B | AX530-A | AX530-B

    HIGH MOUNTING VERSATILITY

    Designed for pusher configurations. Features rear shaft output for internally mounted installations and  front shaft output for externally mounted installations, adapting to diverse airframe layouts.

    ax

    AX435-A | AX435-B | AX525-A | AX525-B | AX530-A | AX530-B

    ENHANCED COOLING EFFICIENCY

    Optimized for pusher applications. End caps incorporate tilted centrifugal cooling fins aligned with rotation direction, improving heat dissipation efficiency by 5%.

    AX435-A | AX435-B | AX525-A | AX525-B | AX530-A | AX530-B

    QUICK INSTALLATION

    Integrated collet-type prop hub enables rapid installation of folding propellers.

    AX525-B Configuration

    Recommended Takeoff Weight

    15-17kg

    Max Thrust

    10kg

    Motor weight

    620g

    Recommended Battery

    12S(Lipo)

    Recommended Setup

    AX525-B Motor+AT115A ESC+ AUFZ18*14 Prop

    Technical Drawing


    Specification Export to Excel
    Model No.AX525-BMagnet Level180℃
    Motor SizeΦ63.6*78.5mmLead CableEnameled Wire 150mm
    Stator150°C high temperature
    -resisting coatings    		Copper Wire220℃
    Configuration12N14PCoil Insulation Test500V/5s
    Shaft DiameterIN:10mm OUT:8mmRotor Dynamic BalanceStandard≤30mg
    BearingImported 6800/6900ZZPackage Size197*104*75mm
    Tech Specs
    KV250Idle Current(15V)2.8A
    Max Power2250WPeak Current100A
    Rated Voltage (Lipo)12SInternal Resistance22mΩ
    Max Thrust10kgWeight (incl.cable)620g
    Test Data Export to Excel
    TypePropellerThrottle
    (%)    		Voltage
    (V)    		Current
    (A)    		Power
    (W)    		RPMTorque
    (N·m)    		Thrust
    (g)    		Efficiency
    (g/W)    		Operating
    Temperature
    (℃)
    AX525-B
    KV250    		AUFZ 18*1440%44.687.0931738420.6219516.1699
    （Ambient
    Temperature：
    25）
    45%44.649.2841442390.7723885.77
    50%44.5712.5956147170.9629685.29
    55%44.4917.1676352381.1836794.82
    60%44.4021.7896756611.3842994.45
    65%44.3226.41117060221.5748704.16
    70%44.2132.09141963961.7855143.89
    75%44.0839.12172467902.0762523.63
    80%43.9247.04206671802.3670413.41
    90%43.5566.83291078642.9884352.90
    100%42.9896.52414985833.76100562.42
    Notes：Motor temperature is the motor surface temperature aftering running at 100% for 1 mins.
    (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation.)
