    U15XL Combo Pack Manned Aircraft Type UAV Motor 38KV Thunder 300A 24S

    1699.00

    Available points: 1699 Points Points reward: 1699 Points

    • Big Power
    • Matched Propulsion solution
    • Stable & Reliable & Safe
    Parameter：
    ESC：
    • Thunder 300A 24S
    Propellers：
    • NS52*20
    Quantity：

    1699.00

    USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

    Combo pack

    Relevant Products

    • Detail information
    • Specifications

    Hot Products

    Technical Drawing


    Specification Export to Excel
    Motor ItemU15XL KV38Weight (Incl. Cable)4408g
    Motor DimensionsΦ151.5*96mmInternal Resistance17mΩ
    LeadEnameled Wire200mmConfiguration36N42P
    Shaft Diameter25mmRated Voltage(Lipo)24S
    Idle Current(10V)3.5APeak Current(120s)180A
    Rated Power3550W

    ESC Itemthunder 300A 24SWeight(Incl. cables)870g
    Size154.9*69.6*48.9mm
    		No
    Programable Item(s)NoSupport Voltage14-24S
    Con. Current240APeak Current(10S)300A
    Model NO.52*20Weight(Single Blade)430±20g
    MaterialCF+EpoxySuface TreatmentGlossy
    T-MOTOR Series2blades-intergrated

    Model NO.57*22Weight(Single Blade)530±20g
    MaterialCF+EpoxySuface TreatmentGlossy
    T-MOTOR Series2blades-intergrated

    Test Data Export to Excel
    TypePropellerThrottleVoltage
    (V)    		Thrust
    (g)    		Torque
    (N*m)    		Current
    (A)    		RPMPower
    (W)    		Efficiency
    (g/W)

    Operating
    Temperature

    (℃)

    U15XL

    KV38

    		52*20“30%99109596.7810.841143106910.30187
    （Ambient

    Temperature：

    32℃）

    35%98142768.7014.85126614619.80
    40%981804010.9420.22144319879.10
    45%982316914.0128.12159627638.40
    50%983043518.4641.30183640527.50
    55%983678622.4453.89198652757.00
    60%984123425.1463.26213361906.70
    65%984495527.4671.78222370176.40
    70%985125431.3386.70234584536.10
    75%975636234.55100.06246697545.80
    80%976110137.45112.782556109575.60
    85%977119443.99142.562712137735.20
    90%977436646.07152.842796147875.00
    95%977795348.23163.702872158354.90
    100%968120650.40175.082910168884.80
    Note: Temperature is motor coiling temperature at 100% throttle running 2mins.
    (Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.)
