    V60A 14S

    129.90

    Available points: 0 Points Points reward: 129 Points

    • Promotion
      • The rest of the store is 10% off
    Quantity：

    129.90

    USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

    • Detail information
    • Specifications
    • Download

    Hot Products

    V60A 14S
    V60A 14SThe advanced edition of FOC ESCsFast response Efficient driving
    Accurate control Low-noise operation
    VL5009/6011
    MOTOR
    V60A
    ESC
    DZ17/P22
    PROPELLER

    Specification

    6~14S

    Support Voltage

    30A

    Con.Current

    60A(10S)

    Peak Current

    63g(excl.cable)/85g

    ESC Weight

    77*33*19mm

    ESC Size

    Technical Drawing

    Specification
    Model No.V60A 14SPower CableSilicone wire-red/black
    -14AWG-160mm
    Size77*33*19mm (L*W*H)Signal CableShielded cables-Black-OD4.2-5C
    -300mm-JP-3P*2-Black blank
    white-green yellow gray
    Weight(Incl. cables)85gEncoder cablesShielded cables-Black-24AWG-5C
    -300mm-M6 aviation connector
    Motor CableSilicone wire-orange-16AWG-60mmProtocolPWM/CAN
    Support Voltage18~60V (6~14S)BECNO
    Continuous Current30AThrottle Pos. Range1040-1940
    Peak Current(<10s)60AThrottle Refresh Frequency50-500HZ
    Standby Consumption≤50mA@48VThrottle Response Speed300ms
