    V200A 14S

    539.90

    Available points: 0 Points Points reward: 539 Points

    • Promotion
      • The rest of the store is 10% off
    Quantity：

    539.90

    USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

    • Detail information
    • Specifications
    • Download

    Hot Products

    V200A 14S
    V200A 14STHE ADVANCED EDITION OF FOC ESCS

    Fast
    response

    Efficient
    driving

    Accurate
    control

    Low-noise
    operation

    recommendation

    VL1028/1032/1035
    MOTOR
    V200A
    ESC
    G29/30/PL32
    PROPELLER

    Specification

    6~14S

    Support Voltage

    100A

    Con. Current

    200A(3S)

    Peak Current

    243g(excl. cable)/470g

    ESC Weight

    127*56*33mm

    ESC Size

    Technical Drawing

    Specification
    Model No.V200A 14SPower CableSilicone wire-red/black
    -10AWG-1120mm
    Size127*56*33mm (L*W*H)Signal CableShielded cables-Black-OD4.2-5C
    -770mm-JP-3P*2-Black blank
    white-green yellow gray
    Weight(Incl. cables)470gEncoder cablesShielded cables-Black-24AWG-5C
    -395mm-M6 aviation connector
    Motor CableSilicone wire-orange-10AWG-205mmProtocolPWM/CAN
    Support Voltage18~60V (6~14S)BECNO
    Continuous Current100AThrottle Pos. Range1040-1940
    Peak Current(<10s)200AThrottle Refresh Frequency50-500HZ
    Standby Consumption≤50mA@48VThrottle Response Speed300ms
