Specification Export to Excel
| Model | X-601KV170 | Lead Cable Length | 630mm |
| Dimension | 124.8*72*110mm | Arm Set Weight(Incl. Cable) | 825g |
| Configuration | 24N28P | Shaft Diameter | IN:6mm OUT:6mm |
| Idle Current (24V) | 0.8A | Rated Voltage (Lipo) | 6-12S |
| Internal Resistance | 115mΩ | ESCRecommendation | ALPHA 60A 12S |
| Max. Power (180s) | 348W | PropellerRecommendation | P20*6 |
| Model | 601-XKV320 | Lead Cable Length | 630mm |
| Dimension | 124.8*72*110mm | Arm Set Weight(Incl. Cable) | 829g |
| Configuration | 24N28P | Shaft Diameter | IN:6mm OUT:6mm |
| Idle Current (24V) | 2.1A | Rated Voltage (Lipo) | 6S |
| Internal Resistance | 39mΩ | ESCRecommendation | ALPHA 60A 6S |
| Max. Power (180s) | 264W | PropellerRecommendation | P20*6 |
Test Data Export to Excel
| Type | Voltage
(V) | Propeller | Throttle
(%) | Current
(A) | Thrust
(g) | Torque
(N.m) | RPM | Motor
Efficiency
(%) | Efficiency(gf/W) | Operating
Temperature
(℃) |
X-601
KV170（Alpha 60A 12S ） | 12S(48V) | P20*6 | 40% | 4.08 | 1732 | 0.48 | 2928 | 74.32 | 10.53 | 67
（Ambient Temperature：
25） |
| 45% | 5.53 | 2201 | 0.60 | 3264 | 76.68 | 9.89 |
| 50% | 7.25 | 2728 | 0.74 | 3592 | 78.55 | 9.31 |
| 55% | 9.28 | 3302 | 0.88 | 3921 | 80.27 | 8.82 |
| 60% | 11.79 | 3927 | 1.05 | 4256 | 81.13 | 8.28 |
| 65% | 14.57 | 4602 | 1.22 | 4580 | 82.24 | 7.86 |
| 70% | 17.78 | 5303 | 1.41 | 4896 | 83.18 | 7.43 |
| 75% | 21.46 | 6036 | 1.60 | 5203 | 83.06 | 6.97 |
| 80% | 25.68 | 6831 | 1.81 | 5516 | 83.32 | 6.62 |
| 85% | 30.31 | 7649 | 2.02 | 5817 | 83.45 | 6.30 |
| 90% | 35.45 | 8476 | 2.24 | 6107 | 83.22 | 5.97 |
| 95% | 40.44 | 9264 | 2.45 | 6372 | 83.20 | 5.74 |
| 100% | 43.26 | 9691 | 2.56 | 6502 | 83.15 | 5.60 |
X-601
KV320（Alpha 60A 6S ） | 6S(24V) | P20*6 | 40% | 6.84 | 1475 | 0.41 | 2738 | 72.09 | 10.78 | 54
（Ambient Temperature：
25） |
| 45% | 9.15 | 1862 | 0.51 | 3045 | 74.49 | 10.20 |
| 50% | 11.95 | 2307 | 0.62 | 3346 | 76.89 | 9.76 |
| 55% | 15.22 | 2759 | 0.74 | 3641 | 78.27 | 9.18 |
| 60% | 19.11 | 3273 | 0.88 | 3937 | 79.23 | 8.71 |
| 65% | 23.47 | 3812 | 1.02 | 4219 | 80.00 | 8.30 |
| 70% | 28.31 | 4357 | 1.16 | 4489 | 80.34 | 7.88 |
| 75% | 33.75 | 4934 | 1.30 | 4751 | 80.63 | 7.53 |
| 80% | 39.77 | 5519 | 1.45 | 5007 | 80.77 | 7.17 |
| 85% | 46.24 | 6088 | 1.60 | 5252 | 80.78 | 6.86 |
| 90% | 52.82 | 6630 | 1.74 | 5467 | 80.63 | 6.57 |
| 95% | 56.19 | 6887 | 1.81 | 5570 | 80.59 | 6.43 |
| 100% | 60.12 | 7012 | 1.90 | 5569 | 80.61 | 6.36 |
Note: Motor temperature is motor surface temperature @100% throttle running 5mins.
(Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.) |
