Specification Export to Excel
| Test Item | Long Shaft KV220 | Weight (Incl. Cable) | 450g |
| Motor Dimensions | Φ60*112.3mm | Internal Resistance | 36mΩ |
| Lead | Enameled Wire 100mm | Configuration | 24N28P |
| Shaft Diameter | IN：10mm
OUT：8mm | Rated Voltage(Lipo) | 6-12S |
| Idle Current(10V) | 1.8A | Peak Current(180s) | 70A |
| Max Power (180S) | 2700W | Recommendation | / |
| Test Item | Long Shaft KV380 | Weight (Incl. Cable) | 465g |
| Motor Dimensions | Φ60*112.3mm | Internal Resistance | 11mΩ |
| Lead | Enameled Wire 100mm | Configuration | 24N28P |
| Shaft Diameter | IN：10mm
OUT：8mm | Rated Voltage(Lipo) | 6S |
| Idle Current(10V) | 4.0A | Peak Current(180s) | 100A |
| Max Power (180S) | 2200W | Recommendation | / |
Test Data Export to Excel
| Type | Propeller | Throttle | Voltage
(V) | Current
(A) | Power
(W) | RPM | Torque
(N*m) | Thrust
(g) | Efficiency
(g/W) | Operating
Temperature (℃) |
AT5220-A
Long Shaft
KV220 | APC
18*8 | 40% | 44.30 | 4.27 | 189.20 | 3585 | 0.383 | 1469 | 7.77 | 81
(Ambient
Temperature: /) |
| 45% | 44.27 | 5.57 | 246.66 | 3980 | 0.460 | 1818 | 7.37 |
| 50% | 44.20 | 8.59 | 379.74 | 4592 | 0.600 | 2446 | 6.44 |
| 55% | 44.13 | 11.17 | 492.86 | 5055 | 0.745 | 3009 | 6.11 |
| 60% | 44.08 | 13.86 | 611.06 | 5473 | 0.857 | 3502 | 5.73 |
| 65% | 44.01 | 16.93 | 611.06 | 5839 | 0.991 | 4080 | 5.48 |
| 70% | 43.93 | 20.49 | 900.27 | 6232 | 1.131 | 4668 | 5.19 |
| 75% | 43.84 | 24.92 | 1092.62 | 6656 | 1.326 | 5323 | 4.87 |
| 80% | 43.75 | 29.00 | 1092.62 | 6969 | 1.466 | 5924 | 4.67 |
| 90% | 43.54 | 38.65 | 1682.85 | 7614 | 1.757 | 7142 | 4.24 |
| 100% | 43.33 | 48.86 | 2116.80 | 8141 | 2.037 | 8185 | 3.87 |
FALCON
18*10 | 40% | 44.30 | 4.71 | 208.48 | 3526 | 0.435 | 1529 | 7.33 | 95
(Ambient
Temperature: /) |
| 45% | 44.26 | 6.17 | 272.92 | 3909 | 0.530 | 1899 | 6.96 |
| 50% | 44.18 | 9.60 | 424.00 | 4500 | 0.697 | 2555 | 6.03 |
| 55% | 44.13 | 12.30 | 542.84 | 4957 | 0.871 | 3100 | 5.71 |
| 60% | 44.06 | 15.45 | 680.69 | 5393 | 1.055 | 3670 | 5.39 |
| 65% | 43.98 | 18.85 | 829.10 | 5756 | 1.185 | 4218 | 5.09 |
| 70% | 43.91 | 22.54 | 989.79 | 6131 | 1.328 | 4818 | 4.87 |
| 75% | 43.79 | 27.63 | 1210.20 | 6541 | 1.486 | 5470 | 4.52 |
| 80% | 43.69 | 32.51 | 1420.65 | 6817 | 1.634 | 5725 | 4.03 |
| 90% | 43.46 | 43.51 | 1891.09 | 7420 | 2.049 | 6819 | 3.61 |
| 100% | 43.22 | 54.71 | 2364.75 | 7936 | 2.354 | 7806 | 3.30 |
FALCON
19*10 | 40% | 44.27 | 5.10 | 225.98 | 3480 | 0.482 | 1730 | 7.66 | 106
(Ambient
Temperature: /) |
| 45% | 44.24 | 6.73 | 297.83 | 3853 | 0.578 | 2172 | 7.29 |
| 50% | 44.15 | 10.39 | 458.61 | 4423 | 0.779 | 2894 | 6.31 |
| 55% | 44.07 | 13.85 | 610.43 | 4895 | 0.929 | 3525 | 5.78 |
| 60% | 43.99 | 17.53 | 771.33 | 5314 | 1.099 | 4220 | 5.47 |
| 65% | 43.92 | 21.04 | 924.14 | 5651 | 1.240 | 4817 | 5.21 |
| 70% | 43.82 | 25.78 | 1129.54 | 6007 | 1.422 | 5554 | 4.92 |
| 75% | 43.71 | 30.89 | 1350.43 | 6387 | 1.585 | 6236 | 4.62 |
| 80% | 43.61 | 35.84 | 1562.82 | 6691 | 1.790 | 6884 | 4.41 |
| 90% | 43.37 | 47.17 | 2045.77 | 7289 | 2.132 | 8240 | 4.03 |
| 100% | 43.11 | 59.53 | 2566.74 | 7781 | 2.468 | 9499 | 3.70 |
Note: Motor temperature is motor surface temperature at 100% throttle running 3mins.
(Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.) |
AT5220-A
Long Shaft
KV380 | APC
18*8 | 40% | 22.02 | 8.48 | 186.80 | 3491 | 0.373 | 1426 | 7.63 | 74
(Ambient
Temperature: /) |
| 45% | 21.96 | 11.05 | 242.62 | 3867 | 0.470 | 1757 | 7.24 |
| 50% | 21.83 | 17.22 | 375.97 | 4437 | 0.614 | 2367 | 6.29 |
| 55% | 21.74 | 21.32 | 463.48 | 4818 | 0.724 | 2787 | 6.01 |
| 60% | 21.63 | 26.63 | 576.14 | 5238 | 0.854 | 3273 | 5.68 |
| 65% | 21.53 | 31.43 | 676.66 | 5536 | 0.939 | 3696 | 5.46 |
| 70% | 21.41 | 37.34 | 799.35 | 5876 | 1.054 | 4117 | 5.15 |
| 75% | 21.24 | 44.95 | 954.74 | 6211 | 1.260 | 4560 | 4.78 |
| 80% | 21.09 | 51.43 | 1084.83 | 6476 | 1.518 | 5000 | 4.61 |
| 90% | 20.78 | 66.45 | 1380.62 | 7006 | 1.698 | 5903 | 4.28 |
| 100% | 20.43 | 82.27 | 1680.38 | 7422 | 1.900 | 6733 | 4.01 |
FALCON
18*10 | 40% | 22.02 | 9.29 | 204.46 | 3393 | 0.387 | 1452 | 7.10 | 81
(Ambient
Temperature: /) |
| 45% | 21.97 | 11.85 | 260.37 | 3748 | 0.461 | 1741 | 6.69 |
| 50% | 21.87 | 16.83 | 368.06 | 4203 | 0.587 | 2215 | 6.02 |
| 55% | 21.73 | 23.19 | 503.81 | 4676 | 0.733 | 2734 | 5.43 |
| 60% | 21.61 | 28.99 | 626.57 | 5080 | 0.885 | 3267 | 5.21 |
| 65% | 21.50 | 34.13 | 733.94 | 5385 | 1.024 | 3687 | 5.02 |
| 70% | 21.37 | 40.60 | 867.53 | 5700 | 1.139 | 4162 | 4.80 |
| 75% | 21.21 | 48.06 | 1019.47 | 6003 | 1.259 | 4651 | 4.56 |
| 80% | 21.07 | 54.89 | 1156.66 | 6270 | 1.370 | 5092 | 4.40 |
| 90% | 20.70 | 72.94 | 1509.93 | 6723 | 1.629 | 5636 | 3.73 |
| 100% | 20.34 | 90.14 | 1833.17 | 7128 | 1.853 | 6328 | 3.45 |
FALCON
19*10 | 40% | 22.00 | 10.36 | 227.99 | 3370 | 0.459 | 1718 | 7.54 | 91
(Ambient
Temperature: /) |
| 45% | 21.94 | 13.29 | 291.53 | 3739 | 0.537 | 2038 | 6.99 |
| 50% | 21.84 | 18.44 | 402.67 | 4155 | 0.685 | 2584 | 6.42 |
| 55% | 21.67 | 26.22 | 568.26 | 4635 | 0.842 | 3168 | 5.58 |
| 60% | 21.53 | 33.20 | 714.61 | 5031 | 1.014 | 3807 | 5.33 |
| 65% | 21.42 | 38.67 | 828.27 | 5325 | 1.114 | 4233 | 5.11 |
| 70% | 21.28 | 45.61 | 970.30 | 5624 | 1.226 | 4684 | 4.83 |
| 75% | 21.10 | 54.16 | 1142.78 | 5924 | 1.364 | 5250 | 4.59 |
| 80% | 20.95 | 61.71 | 1292.68 | 6172 | 1.479 | 5697 | 4.41 |
| 90% | 20.58 | 79.40 | 1634.41 | 6640 | 1.716 | 6703 | 4.10 |
| 100% | 20.21 | 96.83 | 1956.90 | 7020 | 1.921 | 7516 | 3.84 |
Note: Motor temperature is motor surface temperature at 100% throttle running 3mins.
(Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.) |
Packing List
Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to "
onlinesales@tmotor.com " in time.
