Specification Export to Excel
| Type | AT1040 | Magnet Temperature Resistance Grade | 180℃ |
| Motor Dimension | Φ110.6*109.8mm | Lead x Length | Enameled Wire 100mm |
| Stator Technology | 150°C High Temperature-resisting Coatings | Temperature Resistance Of Enameled Wires | 220℃ |
| Configuration | 24N28P | Coil Pressure-resistant | 1000V/5s |
| Shaft Diameter | IN:15mm
OUT:12mm | Dynamic Balance Requirements Standards | ≤30mg |
| Bearings | 6902/6202ZZ Bearings | Packing Size | 246*162*139mm |
| KV | 90 | Idle Current (15V) | 4.9A |
| Max. Continuous Power | 6000W | Peak Current | 105A |
| Rated Voltage (LiPo) | 24S | Internal Resistance | 8.8mΩ |
| Max Thrust | 32kg | Weight (Incl.cable) | 2200g |
Test Data Export to Excel
| Type | Propeller | Throttle
(%) | Voltage
(V) | Current
(A) | Power
(W) | RPM | Torque
(N·m) | Thrust
(g) | Efficiency
(g/W) | Operating
Temperature
(℃) |
AT1040
KV90 | 27*12 | 40% | 88.31 | 24.40 | 2155 | 4052 | 3.74 | 10846 | 5.03 | 117
（Ambient
Temperature: 33℃） |
| 45% | 88.23 | 29.58 | 2610 | 4346 | 4.35 | 12624 | 4.84 |
| 50% | 88.01 | 44.27 | 3896 | 5016 | 5.92 | 17111 | 4.39 |
| 55% | 87.95 | 47.71 | 4196 | 5155 | 6.28 | 18147 | 4.32 |
| 60% | 87.89 | 51.32 | 4511 | 5293 | 6.65 | 19175 | 4.25 |
| 65% | 87.83 | 55.92 | 4911 | 5458 | 7.13 | 20474 | 4.17 |
| 70% | 87.73 | 62.11 | 5449 | 5654 | 7.72 | 22122 | 4.06 |
| 75% | 87.62 | 68.25 | 5980 | 5834 | 8.31 | 23683 | 3.96 |
| 80% | 87.55 | 72.85 | 6378 | 5971 | 8.75 | 24875 | 3.90 |
| 90% | 87.33 | 86.73 | 7573 | 6312 | 9.96 | 28020 | 3.70 |
| 100% | 87.10 | 107.02 | 9321 | 6731 | 11.52 | 29953 | 3.21 |
| 28*10 | 40% | 88.37 | 23.88 | 2110 | 4095 | 3.63 | 10995 | 5.21 | 116
（Ambient
Temperature: 33℃） |
| 45% | 88.27 | 29.34 | 2590 | 4425 | 4.26 | 12882 | 4.97 |
| 50% | 88.04 | 42.82 | 3770 | 5058 | 5.67 | 17074 | 4.53 |
| 55% | 87.98 | 45.97 | 4045 | 5190 | 5.98 | 18075 | 4.47 |
| 60% | 87.93 | 49.62 | 4363 | 5332 | 6.33 | 19148 | 4.39 |
| 65% | 87.86 | 54.28 | 4768 | 5502 | 6.80 | 20481 | 4.30 |
| 70% | 87.75 | 60.03 | 5267 | 5695 | 7.35 | 22076 | 4.19 |
| 75% | 87.65 | 65.90 | 5776 | 5877 | 7.88 | 23646 | 4.09 |
| 80% | 87.59 | 69.67 | 6102 | 5992 | 8.24 | 24634 | 4.04 |
| 90% | 86.79 | 84.47 | 7331 | 6357 | 9.56 | 28170 | 3.84 |
| 100% | 86.36 | 104.38 | 9015 | 6765 | 11.14 | 32003 | 3.55 |
| 29*12 | 40% | 88.59 | 25.59 | 2267 | 3912 | 4.43 | 11864 | 5.20 | HOT
（Ambient
Temperature: 33℃） |
| 45% | 88.48 | 31.73 | 2808 | 4230 | 5.20 | 13961 | 5.00 |
| 50% | 88.41 | 39.03 | 3451 | 4535 | 6.10 | 16442 | 4.80 |
| 55% | 88.19 | 52.35 | 4617 | 5046 | 7.58 | 20445 | 4.40 |
| 60% | 88.25 | 57.79 | 5100 | 5204 | 8.15 | 22024 | 4.30 |
| 65% | 88.09 | 63.49 | 5593 | 5379 | 8.76 | 23661 | 4.20 |
| 70% | 88.03 | 70.21 | 6181 | 5544 | 9.47 | 25445 | 4.10 |
| 75% | 87.90 | 75.74 | 6658 | 5700 | 10.06 | 26733 | 4.00 |
| 80% | 87.95 | 81.56 | 7173 | 5814 | 10.60 | 27972 | 3.90 |
| 90% | 87.63 | 98.46 | 8628 | 6192 | 12.11 | 31458 | 3.60 |
| 100% | 87.27 | 120.52 | 10518 | 6591 | 13.94 | 33242 | 3.20 |
Notes: Motor temperature is the bell temperature aftering running at 100% for 3 mins.
（Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation.） |
Packing List
Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to "
