P2207 V2.0 5"Freestyle Fpv Drone Motor 4-6S KV1750/KV1950/KV2550

21.90

Available points: 1000 Points Points reward: 21 Points

KV：

KV1750
KV1950
KV2550

Quantity：

21.90

USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

Detail information
Specifications

Hot Products

Technical Drawing

Specification

Test Item	1750	Configuration	12N14P
Internal	61.2mΩ	Motor Dimensions	Φ28.1*31mm
Shaft Diameter	4mm	Lead	20#150mm
Weight (Incl. Cable)	33.9g	Weight (Excl.Cable)	30.6g
Rated Voltage(Lipo)	6S	Idle Current(10V)	1.2A
Max. Power(60s)	794W	Peak Current(60s)	35.7A

Test Item	1950	Configuration	12N14P
Internal	56.5mΩ	Motor Dimensions	Φ28.1*31mm
Shaft Diameter	4mm	Lead	20#150mm
Weight (Incl. Cable)	33.7g	Weight (Excl.Cable)	30.4g
Rated Voltage(Lipo)	6S	Idle Current(10V)	1.1A
Max. Power(60s)	878W	Peak Current(60s)	39.3A

Test Item	2250	Configuration	12N14P
Internal	42mΩ	Motor Dimensions	Φ28.1*31mm
Shaft Diameter	4mm	Lead	20#150mm
Weight (Incl. Cable)	33.7g	Weight (Excl.Cable)	30.4g
Rated Voltage(Lipo)	4~5S	Idle Current(10V)	2A
Max. Power(60s)	560W	Peak Current(60s)	38.3A

Test Data

Type	Propeller	Throttle	Thrust (g)	Voltage (V)	Current (A)	RPM	Power (W)	Efficiency (g/W)	Operating Temperature (℃)
P2207V2 KV1950	T5143S	50%	578.71	23.75	7.9	20113	187.67	3.08	84 (Ambient Temperature: 8℃)
		55%	686.64	23.7	10.14	21122	240.43	2.86
		60%	689.15	23.65	11.17	23117	264.12	2.61
		65%	862.97	23.6	13.76	24438	324.62	2.66
		70%	908.32	23.54	15.21	26026	358	2.54
		75%	938.57	23.49	17.64	27051	414.51	2.26
		80%	992.22	23.43	21.68	28035	507.86	1.95
		85%	1025.02	23.36	24.41	29194	570.33	1.8
		90%	1130.91	23.28	27.84	30076	648.27	1.74
		95%	1292.78	23.21	30.89	31005	716.83	1.8
		100%	1378.61	23.1	32.73	31291	755.89	1.82
	T5146	50%	672.86	23.75	8.3	19608	196.98	3.42	89 (Ambient Temperature: 8℃)
		55%	785.9	23.67	10.82	20660	256.11	3.07
		60%	812.27	23.54	12.15	22565	286.05	2.84
		65%	977.62	23.43	14.94	23873	350.04	2.79
		70%	1076.95	23.32	16.94	25160	394.98	2.73
		75%	1116.83	23.2	19.74	26264	457.98	2.44
		80%	1138.51	23.07	23.59	27108	544.22	2.09
		85%	1192.52	22.94	26.88	28056	616.51	1.93
		90%	1290.41	22.74	30.18	28765	686.25	1.88
		95%	1477.74	22.54	33.58	29320	756.79	1.95
		100%	1544.04	22.34	35.26	29506	787.74	1.96
	T5147	50%	685.88	23.74	9.02	19254	214.17	3.2	90 (Ambient Temperature: 8℃)
		55%	812.27	23.66	11.7	20192	276.71	2.94
		60%	815.81	23.56	13.04	22182	307.16	2.66
		65%	986.8	23.45	15.74	23443	369.01	2.67
		70%	1065.06	23.29	17.91	24908	417.06	2.55
		75%	1140.83	23.16	20.78	25722	481.14	2.37
		80%	1144.53	23.01	24.61	26567	566.26	2.02
		85%	1166.48	22.89	27.52	27478	629.88	1.85
		90%	1272.88	22.68	30.94	28009	701.67	1.81
		95%	1466.33	22.48	34.32	28667	771.45	1.9
		100%	1521.15	22.26	35.71	28904	794.94	1.91
	T4943	50%	490.17	23.75	7.25	19264	172.17	2.85	84 (Ambient Temperature: 8℃)
		55%	577.72	23.65	9.26	20203	219.04	2.64
		60%	582.91	23.54	10.28	22085	242.01	2.41
		65%	738.3	23.43	12.67	23403	296.83	2.49
		70%	796.84	23.29	14.26	24981	332.23	2.4
		75%	850.03	23.17	16.88	26178	391.14	2.17
		80%	864.13	23.03	20.35	27186	468.73	1.84
		85%	917.97	22.9	23.41	28323	536.02	1.71
		90%	1000.26	22.69	26.4	29469	599.07	1.67
		95%	1184.39	22.5	29.81	30186	670.74	1.77
		100%	1369.12	22.31	32.15	30212	717.25	1.91
P2207V2 KV2550	T5143S	50%	465.91	16.04	8.36	17150	134.05	3.48	85 (Ambient Temperature: 8℃)
		55%	535.63	15.97	10.18	18305	162.49	3.3
		60%	613.38	15.88	12.35	19572	196.1	3.13
		65%	698.2	15.79	14.75	20835	232.84	3
		70%	782.66	15.69	17.4	21948	273.03	2.87
		75%	857.58	15.58	20.21	22964	314.87	2.72
		80%	922.57	15.47	23.1	24013	357.3	2.58
		85%	988.23	15.36	25.66	24746	394.08	2.51
		90%	1037.71	15.18	28.1	25333	426.73	2.43
		95%	1120.01	15.02	31.26	26159	469.48	2.39
		100%	1226.21	14.83	34.5	26804	511.86	2.4
	T5146	50%	530.28	15.96	9.01	16812	143.78	3.69	87 (Ambient Temperature: 8℃)
		55%	605.62	15.87	11.1	17936	176.16	3.44
		60%	691.06	15.78	13.53	19034	213.53	3.24
		65%	775.89	15.68	16.09	20195	252.25	3.08
		70%	865.32	15.51	18.93	21171	293.65	2.95
		75%	938.61	15.39	21.6	22200	332.42	2.82
		80%	1023.03	15.25	24.88	23051	379.47	2.7
		85%	1106.63	15.11	28.3	23860	427.5	2.59
		90%	1155.85	14.98	30.72	24576	460.23	2.51
		95%	1216.63	14.81	33.79	25199	500.54	2.43
		100%	1263.81	14.61	37.32	25650	545.31	2.32
	T5147	50%	556.58	15.98	9.37	16524	149.73	3.72	89 (Ambient Temperature: 8℃)
		55%	629.46	15.9	11.49	17624	182.78	3.44
		60%	711.78	15.81	13.9	18702	219.68	3.24
		65%	786.19	15.66	16.49	19782	258.2	3.04
		70%	879.9	15.54	19.44	20710	302.18	2.91
		75%	964.01	15.41	22.34	21728	344.31	2.8
		80%	1047.2	15.27	25.45	22427	388.76	2.69
		85%	1114.76	15.13	28.6	23395	432.73	2.58
		90%	1178.07	14.97	31.69	24060	474.29	2.48
		95%	1237.26	14.8	34.63	24567	512.43	2.41
		100%	1288.34	14.6	38.39	24934	560.5	2.3
	T4943	50%	404.58	16.48	7.64	17724	125.89	3.21	82 (Ambient Temperature: 8℃)
		55%	477.46	16.4	9.76	18824	160.15	2.98
		60%	559.78	16.31	12.17	19902	198.43	2.82
		65%	634.19	16.16	14.76	20982	238.49	2.66
		70%	727.9	16.04	17.71	21910	284.15	2.56
		75%	812.01	15.91	20.61	22928	327.96	2.48
		80%	895.2	15.77	23.72	23627	374.2	2.39
		85%	962.76	15.63	26.87	24595	419.99	2.29
		90%	1026.07	15.47	29.96	25260	463.38	2.21
		95%	1085.26	15.3	32.9	25767	503.28	2.16
		100%	1136.34	15.1	36.66	26134	553.57	2.05
Note: Motor temperature is motor surface temperature @100% throttle running 1mins. (Date above based on benchtest are for reference only. Comparion with that of other motor types is not recommended.)

Packing List

Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to " onlinesales@tmotor.com " in time.
