    AM66A or AM Link 3D

    43.00

    Available points: 2000 Points Points reward: 43 Points

    • Packaging Weight：147.7g，Packaging size：119*85*65mm
    Pack：
    • AM LINK
    • AM66A
    Quantity：

    43.00

    USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

    Relevant Products

    • Detail information
    • Specifications

    Hot Products

    Technical Drawing

    Specification
    ESC Size56.6*38.8*18.5mmoutput Wire80mm-14AWG
    Weight63.4gOutput plug3.5gold plugs (Female)
    Power Wire140mm-14AWGSignal Wire290mm（black+red+white）
    Power PlugWithout PlugSignal-return Wire290mm(Brown+red+orange)
    Battery3-6S LipoUBEC Output Current10A
    Rated current66AData Transmission CardAM LINK
    Peak Current86AESC Programming CardAM LINK
    UBEC Output Voltage5.8V-7.4-8.2VESC Programming softwarewindows，android
    Note: All the wire length above is the original length not the length you see from the outside
    Packing List

    Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to " onlinesales@tmotor.com " in time.
